English - 15
Anchor points number and positions
Frame set 4×4 5×5 6×6 8×8
Anchor points
(horizontal x vertical)
3×2 4×3 5×3 6×5
Horizontal distance 608 mm 608 mm 608 mm Distance center:
1216 mm
Others: 608 equally
Vertical distance 1026 mm 684 mm equally Distance top row –
middle row: 1026
mm
Distance middle
row – bottom row:
684 mm
Distance Bottom
row: 342 mm,
others 684 mm
equally
Anchor size Ø10 mm Ø10 mm Ø10 mm Ø10 mm
4. Make the holes at the anchor positions
• Make holes at the anchor positions using a suitable tool.
• Use screw anchors/anchor plugs as required.
• Remove the dust or dirt, and wipe off any drilling chips and dust.
