English - 152
8. Redundancy setting method
8.1 Conguring the settings with two LED controllers connected to the PC using LAN cables
Connect the LED controllers and the LED displays with LAN cables.
Terminate the Backup system connection at the RJ-45 connector located top left on the last display in the daisy
chain connection.
HUB
LED controllers
LED displays
Main (Primary)
Backup
* For the MCTRL 4K LED controller, the way to make connections is similar to this example.
Start the control software NovaLCT and log in with the administrator privileges (English-44).
Click “Screen Conguration”.
