EN - 13

3. OVERVIEW OF

YOUR MACHINE

7 8

9

10

11

123

4

5

6

3.1 General Appearance

1. ElectronicDisplay

2. ProgrammeDial

3. Upper Tray

4. Detergent Drawer

5. Drum

6. PumpFilterCover

7. Power Cord

8. DrainHose

9. Transport Screws

10. Adjustable Feet

11. PlasticDrainHoseHolder:(Donot

removetheholder;theoperationofthe

machinewillbeaffected).

4. INSTALLATION

4.1 Removing the Transit Bolts

X X4 4

X

4

1

3

2

4

1. Beforeoperatingthewashingmachine,

removethe4transitboltsandrubber

spacersfromtherearofthemachine.

If the bolts are not removed, they

maycauseheavyvibration,noiseand

malfunctionofthemachineandvoidthe

warranty.

2. Loosenthetransitboltsbyturning

themanticlockwisewithanappropriate

spanner.

3. Removethetransitboltswithastraight

pull.

4. Fittheplasticblankingcapssuppliedin

theaccessoriesbagintothegapsleft

bytheremovalofthetransitbolts.The

transitboltsshouldbestoredforfuture

use.

NOTE: Removethetransitbolts

beforeusingthemachineforthefirsttime.

Faultsoccurringduetothemachinebeing

operatedwithtransitboltsfittedareoutof

the scope of the warranty.
