XPT800 – Sound Level Meter and Spectrum Analyzer
V1.0
Page 118 of 124
20.4.1 Enabling Spectrum exceedances
From graphic interface access the spectrum view (or EDIT APP/SEL.VIEW/SPECTRUM)
•
Tap the bell to access the setting
•
BANDS: select SINGLE or ALL
SINGLE (reaching the conditions of at least one band generates the surplus)
ALL (reaching of exceedance conditions must be true for all bands)
•
Select required MODE (see 20.1.2 Exceedance SLM mode (Exc_slm_mode) on page 113)
•
Activate the exceedance switching the cursor to ON
With exceedance activated, the bell icon in the spectrum view changes from gray to white (or black
depending on the display colour mode).
When the set conditions for exceedances are reached, the bell turns red and a trigger is generat-
ed.
20.5 Trigger I/O Input
The input can be used to receive (Trigger IN) or send (Trigger OUT) electrical signals.
The input settings can be modified from SETTINGS/TRIGGER/TRGIO
20.5.1 TRGOUT polarity
Sets the polarity of the output trigger signal
POS: the polarity of the output signal is positive
NEG: the polarity of the output signal is negative
20.5.2 TRIGIN polarity
Sets the polarity of the input trigger signal
POS
IN
20.5.3 TRGOUT Mode
Sets the mode of the output trigger signal
OFF
MEAS
TRG
