XPT800 – Sound Level Meter and Spectrum Analyzer
V1.0
Page 11 of 124
3 Identification
3.1 Product identification
•
The serial number is printed on the label on the back panel.
•
The microphone model and serial numbers are engraved on the outside of the microphone.
•
The preamplifier model and serial numbers are engraved on the outside surface of the preampli-
fier.
Information regarding product identification can be found by accessing the page SETTINGS > IN-
STRUMENT > IDENTIFICATION.
3.2 Part numbers of main components and accessories
The following are the codes of the main components and accessories mentioned in the manual and
related to the use of the XPT800 model.
Code
Description
XPT800
Sound Level Meter
MP800
Single range microphone preamplifier
MC800
Precision microphone
WS90
90 mm Windscreen
WSO
Outdoor microphone protection
WSO-C
Outdoor microphone protection with built-in acoustic calibration sys-
tem controlled by XPT800
NS-ENS
Data processing software module
CPL-4.5
5 m microphone extension cable
CPL-4.10
10 m microphone extension cable
HD2020
Class 1 acoustic calibrator, 94-114 dB. Frequency 1 kHz
Firmware and hardware options are covered in the section “5.3 Options and accessories” on page 29.
3.3 Explanation of product code
Code
Description
XPT800
•
XPT: indicates the product line
•
1
st
number: Leading Group (8=Sound & Vibration)
•
2
nd
number: Subunit (0=Sound Pressure Levels)
•
3
rd
number: level of functionality (0= higher level)
Any other numbers separated by a space may be present and follow
the three-number code to indicate additional product features (e.g.,
number of channels or other information)
As for option codes these are preceded by a letter F if it is a firmware option or letter H if it is a
Hardware option. They are always preceded by the code for the instrument to which they refer e.g.
XPT800-OF1E refers to an option of the XPT800 model, Firmware Option.
