PRO 241-2 / PRO 245-2 – Absolute manometers
V10
Page 13 of 27
6 Configuration
Press the MENU key to enter the configuration menu.
The menu is structured in levels. The current level is indicated by the number of overlapping
bars in the menu header:
Use the down/up arrow keys to select an item, press OK to confirm.
The presence of the scroll bar indicates that there are additional items available beyond those
displayed.
The left function key (Help) provides a description of the selected item. If the help function is
entered, press the left function key (Help off) again to exit.
The right function key (+ F menu or – F menu) adds or remove the selected item to or from the list
of favorite functions [ p.16].
Attention!
It is not possible to access the menu if the instrument is logging.
6.1 Menu structure
The menu structure is shown below; each item is preceded by the level according to the bar
symbology shown on the display.
MENU
DESCRIPTION
‒ Measures list
Selection of the quantities to display and log
‒ Recording
Only PRO 245-2
= Start recording
Automatic logging start
= Set interval
Setting of logging interval: 1/2/5/10/15/30 s, 1/2/5/10/15/30 min, 1 h
= Mode
Setting of single recording mode
= Single recording
Manual storing of the current measurements (single sample)
‒ Chart setup
Setting of the measurement graphical display
= Channel select
Selection of parameters to be displayed graphically (selectable from those
enabled in the "Measures list" menu)
= Chart interval
Chart measurement interval: 1/2/5/10/15/30 s, 1/2/5/10 min
Header
Menu items
Help on
selected item
Scroll bar
Level
Favorite functions
management
