PRO 211-x / PRO 215-x – Differential manometers
Page 14 of 24
6.1 Menu structure
The menu structure is shown below; each item is preceded by the level according to the bar
symbology shown on the display.
MENU
DESCRIPTION
‒ Measures list
Selection of the quantities to display and log
‒ Recording
Only PRO 215-x
= Start recording
Logging start
= Set interval
Setting of logging interval: 1/2/5/10/15/30 s, 1/2/5/10/15/30 min, 1 h
‒ Chart setup
Setting of the measurement graphical display
= Channel select
Selection of parameters to be displayed graphically (selectable from those
enabled in the "Measures list" menu)
= Chart interval
Chart measurement interval: 1/2/5/10/15/30 s, 1/2/5/10 min
‒ USB mode
Configurable only in PRO 215-x between COM interface (for logging and
serial communication) or Mass storage (for viewing logging files from
PC). In PRO 211-x the mode is always COM interface.
‒ Alarm settings
Type of alarm signaling: Off, acoustical (buzzer) and/or optical (flashing
backlight and red flashing status LED)
‒ Settings
= Device info
Displaying of instrument info (model, S/N, FW revision, …)
= Backlight
Backlight configuration
≡ BL activation
Backlight duration: Off, 5 s, 30 s, 1 min, always On
≡ BL intensity
Backlight intensity: Low, Medium, High
= Auto-off
Auto-off setting: Off, 30 min, 1/2/4/6/12 h
= Date & time
Setting of date and time (yyyy-mm-dd hh:mm:ss)
= Time zone
UTC or CET time zone setting
= Language
Selection of the menu language
= Dark mode
Black background enabling/disabling
= Factory reset
Reset to factory settings
‒ Pressure sensor
Measurement settings
= Measures units
Setting of the unit of measurement
The units available depend on model (see technical specifications)
= Alerting
Alarm thresholds enabling/disabling
= Min. alarm
(*)
Lower alarm threshold (alarm if measure < threshold)
= Max. alarm
(*)
Upper alarm threshold (alarm if measure > threshold)
= Hysteresis
(*)
Thresholds hysteresis
= Correction
Measurement adjustment
≡ Zero point
Offset adjustment
≡ Gradient
Slope adjustment
= Probe info
Information on the sensor
(*)
The item does not appear if "Alerting" is set to "Off"; to display the item, first select a meas-
ure/channel to associate the alarm with.
To go back up one level within the menu, press the key. The MENU key allows exiting the
menu directly and return to measurement mode from any level (except from parameter
