PRO 111 / PRO 115 – Pt100 thermometers
Page 23 of 25
13 Technical specifications
Measurement specifications
Measuring range
-200.00…+850.00 °C / -328.00…+1562.00 °F
Resolution
0.01 °C/°F
Accuracy
±0.05 °C or ±0.06% of measured value (whichever is
higher) ± 1 digit
Linearization
According to IEC 60751
Measurement rate
2 meas./s
Long-term drift
±0.02 °C/year
Probe cable length
10 m
General specifications
Input channels
1 for 4-wire Pt100 probes
M12 connector
Storage capacity (only PRO 115)
Up to 1 million data sets, file system based (CVS files).
Each data set includes measurement and date/time
stamp.
Logging type (only PRO 115)
Automatic with manual start/stop
Logging interval (only PRO 115)
1, 2, 5, 10, 15, 30 s / 1, 2, 5, 10, 15, 30 min / 1 h
Clock
User settable RTC
Max. drift 1 min/month @ 25 °C
Display
140 x 160 dot matrix backlit LCD
Visible area 42 x 50 mm
User interface
Multilingual
PC connection
USB-C, Mass Storage Device (only PRO 115)
Power supply
4 x AA alkaline batteries
External 5 Vdc via USB C
Power consumption
20 mA typ.
Battery autonomy
> 150 h typ. continuous operation (backlight off)
Auto power off
Yes, user configurable
Operating conditions
-5…50 °C / 0…85 %RH non-condensing
Storage temperature
-25…65 °C (without batteries)
Protection degree
IP 67 (except probe connection)
IK 06
Dimensions
170 x 78 x 38 mm
Weight
340 g approx.
Housing material
ABS, TPE (side protection), Polyester (front panel)
