PRO 111 / PRO 115 – Pt100 thermometers
Page 10 of 25
One parameter displayed numerically and graphically.
The parameters that can be displayed graphically are selectable in
the Chart setup → Channel select menu. The left function key Set-
tings is a shortcut to the Chart setup menu.
A graph for each of the chosen parameters is displayed. Use the
down/up arrow keys to scroll through the various graphs.
To enable/disable the display of a parameter, change the units of measurement or the order
in which parameters are displayed, see the Configuration chapter [ p.12].
5.1 Hold function
The Hold function, which can be activated/deactivated by pressing the right function key,
freezes the current measurement value on the display.
The function activation is highlighted by the hld symbol in the status bar of the display.
5.2 Rel function
The Rel function displays the relative measurement against a reference value, consisting of
the measurement value at the time the function is activated.
To activate the relative measurement, press the left function key (Rel ∆), select with the
down/up arrow keys the measurement for which the function should be activated (the selected
measurement is highlighted in negative), then press the left function key (∆ on). The symbol ∆
and the reference value appear on display.
To disable the relative measurement, press the left function key (∆ off) again.
By pressing the right function key (Exit ∆), the instrument exits the relative measurement en-
able/disable (∆ on/off) mode.
The Rel ∆ command is not available:
• in the screen with the statistical values;
• in the screen with the graph;
• while logging.
