ECO 531 - Dissolved oxygen measuring device Technical data
B-H86.0.2X.DK2-4.0 Page 22 of 24
8 Technical data
Sensor Permanently connected oxygen sensor
Measuring range
O
2
concentration 0.0 .. 20.0 mg/l
0.0 .. 20.0 ppm
O
2
saturation 0 .. 200 %
Temperature 0.0 .. 50.0 °C (32.0 .. 122.0 °F)
Accuracy
(at nominal temperature)
O
2
concentration ± 1.5 % of measured value ± 0.2 mg/l
O
2
saturation ± 1.5 % of measured value ± 2 %
Temperature ± 0.3 °C
Temperature compensation 0 .. 50 °C (or 32 .. 122 °F)
Measuring cycle approx. 2 measurements per second
Display 3- line segment LCD, additional symbols, illuminated
(adjustable white, permanent illumination)
Standard functions Min/Max/Hold
Adjustment Offset and gradient correction for temperature,
callable automatic O
2
-calibration at the air
Housing Break-proof ABS housing
Protection rating IP65 / IP67
Dimensions L*W*H 108 * 54 * 28 mm, without electrode or kink protection
Weight 240 g incl. battery and electrode
Nominal temperature
Device -20 to 50 °C; 0 to 95 %RH (temporarily condensing)
Electrode 0 .. 40 °C
Storage temperature 0 .. 40 °C
Current supply 2 * AA batteries (mignon)
Current requirement approx. 0.8 mA, approx. 2.7 mA with lighting
