ECO 240-.. - Vacuum meter | barometer Measurement Basics
B-H88.0.1X.DK2-2.0 Page 15 of 24
5.3 Pressure Connection
Note
Suitable hoses must be used for vacuum measurements, silicon is suitable as a hose material
due to the low rigidity!
Caution Air pressure at port variant UT!
With higher pressures greater than 1 bar, the hoses must be secured to prevent
unintended loosening. Suitable GDZ hose clamps are used for this purpose.
6x1 mm PVC (GDZ-01) up to 5 bar rel., vacuum-suitable!
6x1 mm PE (GDZ-02) up to 10 bar rel., vacuum-suitable!
6x1 mm PUR (GDZ-03) up to 9 bar rel., vacuum-suitable!
5.3.1 Replacement of pressure hoses
The pressure connections are screwed into the product with a standard G 1/8 inch thread
with end seal. All common pressure connections with this design can be connected.
Note
Use a suitable tool for tightening and observe the maximum torque of 2 Nm!
