INSTALLATION
EN/1
P
Procedure for fixing
x Dimensional Drawings
x Follow the directions of the template for drilling
x Fix the hood as shown in the scheme
Connecting and fitting
Before connecting the appliance, check the household installation.
Appliance without power cable:
Only connect as shown the connection diagram. If
necessary, fit the copper bridge supplied. Mains power cable: Type H05 VV-F or a higher
grade, min. wire cross-section 1.5 mm2.
Appliance with prefitted power cable:
The power cable must only be replaced by a
trained after-sales engineer.
Installing:
Do not trap the power cable and do not route it over sharp edges. If the oven
is a built-under type, route the cable on the rear corners of the oven to the socket.
Electrical Connection
Connect the device to the mains and check the operation:
x voltage, see the rating plate
x connect adhering strictly to the relevant diagram
1. Brown
2. Blue
3. Yellow and Green
Wiring Diagram
