6
b. For fanless power supplies, Sea Sonic recommends to mount fanless power supplies into
the computer case with their ventilation cover facing UPWARDS. However, there are extra
mounting-screw holes provided on the back of the power supply to allow for reverse
mounting, if necessary
2. Mainboard connection:
a. DO NOT force the connectors into place; the connectors are “keyed” so they can only t one
way. Make sure the connectors lock in their place securely.
b. Connect the power supply end of the 24/20-Pin convertible connector to the appropriate
receptor on the power supply unit.
c. Connect the mainboard end of the 24/20-Pin convertible connector to the mainboard.
Depending on the mainboard, you may need to either attach or detach the 4-Pin module of
the 24/20-Pin connector.
d. Connect the + 12 V 4-Pin connector and the EPS + 12 V connector, if applicable.
e. If your system requires dual EPS + 12 V connectors, please connect the 8-Pin end of the
second CPU 8-Pin connector into the appropriate 8-Pin receptor on the power supply unit.
Then connect the mainboard end of this 8-Pin connector to the mainboard.
3. Peripheral components connection:
a. Connect one end of the peripheral cable to the power supply and the other end to the
component.
ENGLISH
