HL- M1120LD INSTRUCTION MANUAL(UPDATED: 2/27/24)
43
Figure 44. Sealer Rack
Item #
Part #
Quantity Description
Reference Comments
1 1
chassis
2 HL-M1120LD-94 4
foot plate bolt
Includes #2, #4
3 4
foot plate support
4 HL-M1120LD-94 4
foot plate
Includes #2, #4
5 4
caster
910205
6 1
right upright post
HL-M1120LD-29 1
motor
Not shown
BS-29A_HL-M1120LD 2
motor brush
Not shown
7 HL-M1120LD-30 4
wormgear case assembly
8 HL-M1120LD-72-8 1
worm support seat
11521040410
9 HL-M1120LD-72-9 1
worm bushing
111078
10 HL-M1120LD-72-10 1
connecting head of handle
111086
11 HL-M1120LD-90 1
handwheel 930107-2
12 HL-M1120LD-72-12 1
right-out support plate for conveyor table
13 HL-M1120LD-72-13 4
rear roller
111071
14 HL-M1120LD-72-14 4
front roller
111070
15 HL-M1120LD-72-15 8
lifting roller shaft
111072
16 HL-M1120LD-72-16 2
lifting sprocket
111080
17 HL-M1120LD-72-17 1
right-inner support plate for conveyor
table
18 HL-M1120LD-72-18 1
lift sprocket shaft
111079
19 HL-M1120LD-72-19 1
left inner support board of conveyor table
20 HL-M1120LD-72-20 1
left out support board of conveyor table
21 HL-M1120LD-72-21 2
shaft sleeve of lift sprocket
111082
22 HL-M1120LD-72-22 2
bearing seat for lift sprocket
111081
23 HL-M1120LD-72-23 2
nut GB/T41-2000
24 HL-M1120LD-72-24 2
screw rod
111085
25 1
left upright post
26 HL-M1120LD-72-26 2
chain
930603
27 2
limiting plate for conveyor table
28 HL-M1120LD-72-28-29 4
chain pin
111084 Includes #28, #29
29 HL-M1120LD-72-28-29 2
chain seat
111083 Includes #28, #29
