HL- M1120LD INSTRUCTION MANUAL(UPDATED: 2/27/24)
41
Figure 42. Conveyor Table
Item #
Part #
Quantity Description
Comments
1 HL-M1120LD-1 1 Conveyor Belt
2 2 Five-Star ( Bakelite )Handle M6×Ф30
3 HL-M1120LD-16 2 Adjustment Screw Includes #3, 4
4 HL-M1120LD-16 2 Adjusting Ring Includes #3, 4
5 HL-M1120LD-16-15 2 Conveyor Belt Adjust Seat
6 HL-M1120LD-36 2 Rear Roller Plug Includes #6, 7, 8, 9
7 HL-M1120LD-36 2 Circlip for Shaft (Ф12mm) Includes #6, 7, 8, 9
8 HL-M1120LD-36 1 Rear Roller Shaft Includes #6, 7, 8, 9
9 HL-M1120LD-36 1 Rear Roller Includes #6, 7, 8, 9
10 6 Deep Groove Ball Bearing 6201-2RS
11 HL-M1120LD-15 1 Working Table
12 HL-M1120LD-36.12 3 Intermediate Roller (Long) Assembly
13 HL-M1120LD-18 2
Baffle Support Rod
Includes #13, 14, 15, 16, 18
14 HL-M1120LD-18 2 Guide Rod Includes #13, 14, 15, 16, 18
15 HL-M1120LD-18 2 Support Rod Support Includes #13, 14, 15, 16, 18
16 HL-M1120LD-18 2 Guide Rod Support Includes #13, 14, 15, 16, 18
17 HL-M1120LD-20-17 1 Conveyor Table
18 HL-M1120LD-18 1 Baffle Support Includes #13, 14, 15, 16, 18
19 HL-M1120LD-41 2 Conveyor Table Middle Shaft Bearing Seat I Includes #29, 20, 21, 22
20 HL-M1120LD-41 1
Conveyor Table Middle Shaft
Includes #29, 20, 21, 22
21 HL-M1120LD-41 2
Conveyor Table Chain Wheel
Includes #29, 20, 21, 22
22 HL-M1120LD-41 1 Middle Shaft Pad Includes #29, 20, 21, 22
23 HL-M1120LD-40A 1 Half-Universal Joint Assembly
24 HL-M1120LD-72_shaft 1 Vertical Shaft
25 HL-M1120LD-37 2 Front (Left) Roller Bearing Seat Includes #25, 26, 27
26 HL-M1120LD-37 2 Front (Left) Roller Includes #25, 26, 27
27 HL-M1120LD-37 1 Front (Left) Roller Shaft Includes #25, 26, 27
28 FRM-1120LD-38-41 1 Three-joint Chain (06B-1×42L) 42 segment
29 HL-M1120LD-30 1 Gear Box
30 HL-M1120LD-1-30 1 Front Baseplate
31 1 Motor Safety Cover
32 HL-M1120LD-29 1 Reducer Motor ask distributor which motor
HL-M1120LD-29-AC 1 AC Motor ask distributor which motor
33 1 Reducer Installing Board
34 HL-M1120LD-1-34 1 Rear Subplate
35 HL-M1120LD-1-1 1 Outfeed Board
