HL- M1120LD INSTRUCTION MANUAL(UPDATED: 2/27/24)
39
Figure 40. Heating/Cooling Blocks & Dry Ink Coding Function
Item #
Part # Quantity Description Reference Comments
1 1 bottom board 106042
2 BS-46 1 ink roller shaft 105036
3 BS-62E-FRM 1 swing pole of ink roller 201007
4 FRM-1120C-47 1 heating block of ink roller 201002
5 BS-48C 1 heating pipe 110v/40w 921301
6 1 printing wheel shaft 106071
7 BS-48-7 1 spring of holding latch on printing wheel
8 BS-48-8 1 cover for printing wheel shaft 201015
9 BS-48B 1 printing wheel 201013
10 BS-48A 1 printing wheel cover 201014 Includes #10, #11
11 BS-48A 1 holding latch for printing wheel 201016 Includes #10, #11
12 1 printing-silicone wheel shaft 201010
13 BS-57A 1 silicone ring 910107
14 BS-57 1 circlip for hole GB/T893.1-1986 Includes #14-17
15 BS-57 1 core of silicone wheel 201011 Includes #14-17
16 BS-57 1 bearing GB/T276-1994 Includes #14-17
17 BS-57 1 eccentric sleeve 201012 Includes #14-17
18 HL-M1120LD-8-18 1 upper cooling block shaft 201019
19 FRM-1120C-8 2 upper cooling block 201015 Includes #19, #23, sold as pair
20 7 flat washer GB/97.1-2002
21 7 cap nut GB/923-1988
22 HL-M1120LD-8-22 1 lower cooling block shaft 106020
23 FRM-1120C-8 1 lower cooling block 106016 Includes #19, #23, sold as pair
24 HL-M1120LD-9-24 2 upper heating block shaft 106021
25 FRM-1120C-9A-SS 1 upper heating block 106017 Includes #25, #27, sold as pair
26 HL-M1120LD-9-26 2 lower heating block shaft 106022
27 FRM-1120C-9A-SS 1 lower heating block 106018 Includes #25, #27, sold as pair
28
29 1 wind catcher 106058
30 FRM-1120C-32 1 fan
31 BS-64B 1 support for brush 106073
32 BS-64A 1 carbon brush holder 920423
33 BS-64C 2 pressing plate of brush 201009
BS-64 2 carbon brush Not shown
34 BS-65 1 groove sensor
35 BS-139-FRM-1120LD 1 electromagnetic clutch assembly A10501
36 BS-54B 1 middle pulley 105032
37 BS-54B-35 1 middle pulley shaft 105035
38 BS-54C-34 1 ink roller shaft pulley 105041
39 BS-54C 1 seat for ink roller swing pole shaft 201006
