HL- M1120LD INSTRUCTION MANUAL(UPDATED: 2/27/24)
35
Figure 36. Sealer Body Front (2 of 2)
x
Part #
Quantity Description
Reference Comments
38 FRM-1120C-13-38 2 cam 106031
39 2 hexagonal bolt
40 FRM-1120C-13-40 2 pressing plate for adjusting block 106027
41 FRM-1120C-13-41 4 spacing ring of pressing plate 106028
42 Screw-M4x8 1
screw
GB/T818-2000 M4x8
43 Screw-M4x8 1
screw
GB/T818-2000 M4x8
44 Screw-M4x8 1
screw
GB/T818-2000 M4x8
45 Screw-M4x8 1
screw
GB/T818-2000 M4x8
46 Washer-M5x16 2 flat washer GB/97.1-2002
47 1 spring seat 106034
48 HL-M1120LD-21-48 2 bearing seat of upper pressing wheel
49 Bearing_6900Z 2 bearing (6201) GB/T276-1994(6201)
50 HL-M1120LD-21-50 2 spacing ring of upper pressing wheel
51 HL-M1120LD-21-51 2 gear of pressing wheel
52 FRM-1120C-6-50-56 3 bearing seat 106008 Includes #18-20, 52-54
53 FRM-1120C-6-50-56 2 spacing ring of bearing 106009 Includes #18-20, 52-54
54 FRM-1120C-6-50-56 6 bearing (6201) GB/T276-1994(6201) Includes #18-20, 52-54
55 FRM-1120C-35B 5 gear 106014
56 2 slide block 106005
57 FRM-1120C-28-49 2 single slide block seat 106004
58 2 hexagon nut
59 Washer-M5x16 2 flat washer GB/97.1-2002
60 2 hexagon nut
61 FRM-1120C-26 2 driving belt (#678)
62 FRM-1120C-10 2 sealing belt (#1120)
63 HL-M1120LD-26-2a 2 driving belt (#980) Determine 2a or 2b
HL-M1120LD-26-2b 2 driving belt (#960) Determine 2a or 2b
