FRM- 1120C INSTRUCTION MANUAL
4
Sealer Sales | www.sealersales.com | Tel: 818-718-8818 | E-mail: contact@sealersales.com
Adjustable 2-way pulley system for optimal stability and embossing clarity
Knurled pressure rolls with variable pressure adjustment
PID digital temperature controller 0-300˚C (572˚F) with dual alphanumeric displays (target & current
temperature)
Motorized rubber conveyor with speed control
Capable of speeds up to 394 inches/minute
How Does the Band Sealer Work?
Our band sealers are comprised of a stainless steel frame, speed adjusting
mechanism, sealing temperature control system and transmission system. Turning
on the heat for the band sealer will cause a rapid rise in the temperature of the heating
blocks. Required temperature and speed can be adjusted via the temperature
controller and speed adjusting device. Plastic material to be sealed is placed on the
guide and conveyor. Conveyor will then take the material between the two heating blocks to fuse the
material together. Material will then pass through the cooling blocks to allow the material to congeal.
Finally, a photoelectric sensor will direct the dry ink coder to print a clear and legible print at the seal line.
The motor drives the sealing belts, drive belts and conveyor simultaneously.
Specifications
FRM-1120C
FRS-1120W
Dry Ink Coding
Hot Stamp Printing
Power
110V/60Hz
Motor Power
100W
Sealing Speed
0-394 inches/minutes
Sealing Width
10mm
Temperature Range
0-300˚C (572˚F)
Conveyor Size
43” x 8”
Max Conveyor Load
22-lbs
Printing Heating Power
40 x 2 (W)
50 x 2 (W)
Character Size
3x5x7mm / 18PT – 2 lines
2x3x7mm / 10.5PT – 3
lines (additional option
available)
2x4x15mm
Printing Colors
Black, White
Black, Blue, Red, White
Dimensions
43” x 24” x 41”
Weight
187lbs (n.w.) / 275lbs (g.w.)
Basic
Principles
FRM-1120C is easy to
use. To seal, adjust
temperature and place
bag on conveyor
