FRM- 1120C INSTRUCTION MANUAL
40
Sealer Sales | www.sealersales.com | Tel: 818-718-8818 | E-mail: contact@sealersales.com
Figure 47. FRS-1120W Spare Parts Overview Parts List
Item
Part #
Quantity Description
Reference Comments
1 FRM-1120C-28a, b or c 5 Adjusting Assembly for FRM-1120C, FRS-1120W 11511010203
2 FRM-1120C-28a, b or c 5 Adjusting Assembly for FRM-1120C, FRS-1120W 11511010204
3 FRM-1120C-28a, b or c 3 Adjusting Assembly for FRM-1120C, FRS-1120W 11511010205.65
4 FRM-1120C-28a 5 Adjusting Assembly for FRM-1120C, FRS-1120W - 65mm 9100411120625
Includes #1-4
5 FRM-1120C-28c 1 Adjusting Assembly for FRM-1120C, FRS-1120W - 92mm 11511010205.92
Includes #1-3, 5
6 FRM-1120C-28b 1 Adjusting Assembly for FRM-1120C, FRS-1120W - 78mm 11511010205.78
Includes #1-3, 6
7 FRM-1120C-6-56 3 Bearing Seat 11511010303
8 3 E-clip 12mm 9746036400012
9 Bearing_6201Z 7 Bearing 6201 Z (12 x 32 x 10) 9105200602011
10 FRM-1120C-6-55 3 Spacing Ring of Bearing 11511010304
11 4 E-Clip 32mm 9746016400032
12 FRM-1120C-6-53 2 Driving Wheel Shaft 11511010402
13 FRM-1120C-6 2 Driving Wheel, Big 11511010401
14 Washer-M5x28 2 Washer M5 x 28 x 2 11511010403
15 1 Rubber Wheel Shaft 11511010302
16 FRM-1120C-2 1 Rubber Wheel 11511010301
17 CBS-880-2-33 1 Silicone Wheel Cover 11111030018
18 FRM-1120C-3A-10 1 Embossing Wheel Shaft 11511010201
19 FRM-1120C-3A 1 Embossing Wheel, Meshed 11511010202
20 FRM-1120C-40A 1 Drive Shaft Connector, Gimbel Assembly A115110107
21 FRS-1120W-HP-241G 1 Imprinter for FRS-1120W A21312105
FRS-1120W-48A 1 Print Head for FRS-1120W
22 FRS-1120W-6B 2 Small Pulley Shaft 11513010101
23 2 Driving Wheel, Small 11311030001
24 Bearing_6062Z 2 Bearing 606-ZZ (17 x 6 x 6) 9105200600062
25 Circlip-17mm 2 E-Clip 17mm 9746016400017
26 FRS-1120W-26 2 Drive Belt (#830mm) 9425100020830
