FRM- 1120C INSTRUCTION MANUAL
30
Sealer Sales | www.sealersales.com | Tel: 818-718-8818 | E-mail: contact@sealersales.com
Figure 35. FRM-120C Spare Parts Diagram Overview Parts List
Item
Part #
Quantity Description
Reference Comments
1 FRM-1120C-28D 5 Adjusting seat for slide block 11511010203
2 5 Leaf shaped washer 11511010204
3 FRM-1120C-28A 1 Adjusting screw for slide block (Length: 65mm) 11511010205.65
Includes #1, 2, 3, 4
3 FRM-112C-28-73-1 Spring ϕ12x22x55.7
4 5 Flower shaped knob
5 FRM-1120C-28C 1 Adjusting screw for slide block (Length: 92mm) 11511010206
Includes #1, 2, 4, 5
5 FRM-112C-28-73-2 Spring ϕ11x0.8x45.2 11511070201
6 FRM-1120C-28B 1 Adjusting screw for slide block (Length: 78mm) 11511010205.78
Includes #1, 2, 4, 6
6 FRM-112C-28-73-2 Spring ϕ11x0.8x45.2
7 BS-62 1 Ink wheel adjusting device
Includes #7, 8
8 BS-62 1 Ink wheel adjusting device
Includes #7, 8
9 FRM-1120C-6-56 1 Bearing seat 11511010303
10 Circlip-12mm 1 Circlip ϕ12mm 9746036400012
11 Bearing_6201RS 3 Bearing 6201RS ϕ12 x ϕ32 x 10 9105200602011
12 FRM-1120C-6-55 1 Spacing ring of bearing 11511010304
13 FRM-1120C-2-16 1 Silicone wheel shaft
14 Circlip-32mm 2 Circlip ϕ32mm 9746016400032
15 FRM-1120C-2 1 Rubber wheel 11511010301
16 CBS-880-2-33 1 Silicone wheel cover 11111030018
17 FRM-1120C-3A-10 1 Embossing wheel shaft
18 FRM-1120C-3A 1 Embossing wheel, meshed
Includes #11, 14, 18
19 BS-60-18 1 Support for photoelectric sensor 11511070223
20 BS-60_Gen2.0 1 Photoelectric sensor 9213203103001
21 FRM-1120C-40A 1 Universal joint assembly A115110107
FRM-1120C-41 1
22 FRM-1120C-57-12 1 Printing rubber wheel shaft 11511070216
23 Circlip-28mm 1 Circlip ϕ28mm 9746016400028
24 Bearing_6001Z 3 Bearing 6001Z ϕ12 x ϕ28 x 8 9105200601012
25 BS-57A 1 Silicone ring 9410202112001
26 BS-57 1 Silicone ring complete
Includes #25, 26
27 BS-57B 1
Eccentric sleeve
11511070215
28 FRM-1120C-26 2 Drive belt 678mm 9425100020678
29 BS-48B 1 Base of print wheel A115110701
30 BS-48A 1 Print wheel A115110702
31 FRM-1120C-6b 2 Small pulley shaft 11511010101
32 FRM-1120C-6a 2 Small driving wheel 11511010102
Includes #32, 33, 34
33 Bearing_6900Z 2 Bearing 6900Z ϕ10 x ϕ22 x 6 9105200619002
34 Circlip-22mm 2 Circlip ϕ22mm 9746016400022
35 BS-62E 1 Swing pole of ink roller 11511070202
36 BS-58 1 Ink roller holder stop 11511070222
Includes #36, 39
37 INKROLLER-30-BLK 1 Black ink roller, 30mm
INKROLLER-15-BLK 1 Black ink roller, 15mm
37 BS-48-6-FRM-1120C 1 Ink roller shaft, 6-3/8" 11511070204-2
38 BS-58 1 Ink roller holder 11511070206
Includes #36, 39
39 BS-61 1 Heating tube, each 9240110100304
40 FRM-1120C-47 1 Ink wheel heating block 11511070210-D1
