FR- 770 INSTRUCTION MANUAL
42
Problem Possible Causes S
olution
Sealing belt is off tracking.
Driving wheel shaft is not parallel to
driven wheel shaft
Adjust two adjusting screws on the adjusting block
seat (Part# CBS-880-13)
Sealing belts are tearing
1. Too much tension on sealing belt
2. Sealing belt is off tracking
3
. Creases on the sealing belt
4. Residual film or other debris
attached to the sealing belt
1. Adjust the vertical adjusting screw on driven
wheel seal to decrease tension on sealing belt
2
. see above
3. When installing belt, make sure no creases are
found on belt
4. Clean surface of belt with cloth
Seal is crumpled and film sticks to
sealing belts
1. Temperature is too high
2. Guide belt is not correctly in place
3
. Plastic melted on the sealing belt
1. Reduce temperature
2. Adjust guide belt
3
. Clean or replace sealing belt
If any plastic melts on the sealing belt, your bags
will stick to the melted plastic
Embossing is not clear
1. Embossing roller is worn out
2. Pressure spring on embossing
r
oller needs to be tightened
1. Replace embossing roller
2. Adjust the embossing roller spring (Part# BS-5)
Material will not pass through
sealing blocks
Clearance between heating blocks or
cooling blocks may be too small
Adjust the clearance between blocks by adjusting
the springs and stopping flakes found above the
bl
ocks
Conveyor belt is off tracking
Driving roller shaft is not parallel to
the driven roller shaft
Adjust using the conveyor belt adjustment (Part#
BS-16)
Conveyor and sealing belt are not
moving at same speed
Not enough tension on conveyor belt
1. Tighten the chain of driving roller shaft (front
shaft) and middle shaft. (Parts # HL-M810-37 and
H
L-M810-41)
2. Tighten the conveyor belt
Temperature doesn't rise or cannot
be controlled
1. Heat switch is damaged
2. Heater (BS-9B) is damaged
3
. Temperature Controller
4. Coupling
Replace:
1. Heat switch (BS-22-Large)
2
. Heater (BS-9B)
3. Temperature Controller
4. Thermocouple
