FR- 770 INSTRUCTION MANUAL
34
Figure 26. Conveyor Table
Item Part # Description Quantity Comments
1
FR-770-1 conveyor belt 1
2
BS-16 adjusting block for conveyor belt 2
Includes #2, 3, 4
3
BS-16 double end bolt 2
Includes #2, 3, 4
4
BS-16 adjusting knob for conveyor table 2
Includes #2, 3, 4
5
HL-M810-36 6201-Z bearing 3
Includes #5, 6, 7, 8
6
HL-M810-36 bearing seat of left roller 2
Includes #5, 6, 7, 8
7
HL-M810-36 rear shaft of conveyor table 1
Includes #5, 6, 7, 8
8
HL-M810-36 rear roller of conveyor table 1
Includes #5, 6, 7, 8
9
HL-M810-18 half-round square neck bolt 2
Includes #9, 11, 12
10
HL-M810-15 worktable 1
specify flat or curved edges
11
HL-M810-18 plastic spacer 2
Includes #9, 11, 12
12
FR-770-18 / BS-17 knob 2
Includes #9, 11, 12
13
FR-770-20 conveyor table 1
14
HL-M810-41 bearing seat 1
Includes #5, 14-18
15
HL-M810-41 middle shaft of conveyor table 1
Includes #5, 14-18
16
HL-M810-41 sprocket of conveyor table 2
Includes #5, 14-18
17
HL-M810-41 connecting shaft bearing 1
Includes #5, 14-18
18
HL-M810-41 bearing 6001 1
Includes #5, 14-18
19
HL-M810-37 two-eye bearing seat 2
Includes #19, 20, 21, 22
20
HL-M810-37 front roller of conveyor table 2
Includes #19, 20, 21, 22
21
HL-M810-37 front shaft of conveyor table 1
Includes #19, 20, 21, 22
22
HL-M810-37 6201-2Z bearing 2
Includes #19, 20, 21, 22
23
FR-770-38 chain (48 segments) 1
