FR- 770 INSTRUCTION MANUAL
30
Figure 22. Heating / Cooling Blocks
Item Part # Quantity Description Comments
1
BS-9I 2 stopping flake
2
CBS-880-9-2 1 upper holding plate
3
BS-9J 2 hanger plate of copper block
4
CBS-880-21-19 1
lower pressing wheel shaft
5
BS-9F 4 self-made hexagon thin nut
6
BS-9D 4 spring for copper block
7
FR-770-9A 1 upper heating block (770)
Includes #7, #9
8
BS-9B 2 300W/110V(Ф12X95) heating pipe for sealing
sold as a pair
9
FR-770-9A 1 bottom heating block (770)
10
CBS-880-9-10 4 copper block cushion
11
CBS-880-9-11 1 bottom holding plate
12
CBS-880-21-23 1 slide seat for pressing wheel
13
CBS-880-21-24 1 upper pressing wheel shaft
14
FR-770-8 1 upper cooling block
Includes #14, #17
15
CBS-880-21 2 61900-2Z bearing
Includes #15, #16
16
CBS-880-21 2 pressing wheel / pinch roller
Includes #15, #16
17
FR-770-8 1 bottom cooling block
Includes #14, #17
CBS-880-21uppercomplete
upper pressing wheel shaft assembly
Includes #12-13, 15-16
CBS-880-21lowercomplete
lower pressing wheel shaft assembly
Includes #4, 15-16
