FR- 770 INSTRUCTION MANUAL
12
3. Use the handles when removing the machine from the box. DO NOT hold the conveyor to move the
machine.
4. Carefully check the contents against the spare parts list (see Spare Parts List on page Error! Bookmark not
defined.). Once you have determined that all of the parts have arrived in good order set up can proceed. If
any parts are missing or appear to be damaged, please notify your distributor or Sealer Sales AND your freight
company at once.
Initial Set-up (Vertical Units Only)
Please note: Initial set up is for vertical configuration (FR-770II) band sealers only.
To prevent damage to the band sealer, the umbrella gear base with
long shaft is shipped disconnected. Please follow these simple
steps to connect the long shaft to the umbrella gear base.
1. Open the panel found at the top of the band sealer.
2. Insert the long shaft through the gear in the band sealer
housing, making sure the groove on the shaft and gears line up.
3. Insert the shaft in the umbrella gear base.
Figure 4. Ensure the groove in the long shaft matches that in the gear
Figure 5. Ensure the groove in the long shaft matches that in the gear
4. Using a screwdriver, screw the long shaft into the Umbrella Gear Base
Please disregard initial set up
instructions if you purchased
the FR-770 horizontal
configuration band sealer.
