SPECIFICATIONS PARTS DIAGRAM
FKR-200 FRK-300 FKR-400
Seal Length 10mm 10mm 10mm
Power 110V / 300W 110V / 400W 110V / 500W
Length 8” 12” 16”
Temperature Up to 300⁰F(150⁰C)
Wei
g
ht 4lbs
OPERATING INSTRUCTIONS
1. Insert power plug into socket.
g
2. Allow the sealer to heat up approximately 5 minutes
(warm-up time will vary with the thickness of the bag to be
sealed). Choose either the low setting for a light material
or a the high setting for thicker materials. We recommend
starting at the lowest setting and gradually moving up as
needed.
3. After a suitable temperature has been reached, put the
bag edge between the heated sealing bars and press
down for 3 seconds. If the seal weld holds, continue this
way. *If the welding appears to damage the bag, apply
pressure on the sealing bar for less than 3 seconds. If the
PARTS LIST
No Description QTY No Description QTY
1 Lever (up) 1 15 Expoxy Washer 16
2 Lever Cover (up) 1 16 Aluminum 8
3 Insulation Plate 1 17 Nylon Nut 4
4
Circuit Set
1
18
Insulation Cover
1
welding appears incomplete, apply pressure for more
than 3 seconds.
4
Circuit Set
1
18
Insulation Cover
1
5 Below Board 1 19 Lever (down) 1
6 Supporter 2 20 Spring 1
7 Heating Bar (down) 1 21 Plate Board 1
8Heater 4 22 Lever Cover 1
9M10 Bolt 4 23 Volume 1
10 Shaft 1 24 Bimetal 1
11 Plain Washer 2 25 Heating Bar (up) 1
12 M6 Bolt 2 26 Code Rock 1
13 Stainless Steel Bolt 4 27 Stainless Steel Nut 8
14 Plain Washer (SUS) 16
