2
1. Description
1.1 Product application
CS-6050 Series Semi-Auto Tape Carton Sealer provides you with modern sealing technology.
It has strong and stable structure, light weight, easy operation and simple maintenance. If it can
be used reasonably according to this instruction, it will have many years of trouble-free working
time.
The Tape Carton Sealer is mainly used for carton packing. It can be used alone or with
assembly line. It is widely used in the packaging of household appliances, textiles, food, beverage,
medicine, cosmetics, books and periodicals. The Tape Carton Sealer uses adhesive tape to seal
cartons, which is economical and fast. It is easy and fast to adjust different cartons at will. It can
also complete the action of top and bottom sealing box at the same time. Three-sided drive
packing machine, generally suitable for heavy cartons.
We require you to read this instruction carefully, keep the machine clean, operate and maintain
according to the instruction to ensure the normal service life of the machine.
1.2 Technical parameters
Model
CS-6050
Voltage (V/Hz)
AC 220/50,110/60
Power (W)
200
Max. Carton Size (W x H x L) (mm)
500×500×∞
Min. Carton Size (W x H x L) (mm)
180×130×130
Sealing Speed (m/min)
20
Height of Table (mm)
635-780
Width of Adhesive Tape (mm)
48/60/76
Used Adhesive Tape
BOPP, water-free adhesive tape, PVC adhesive tape
Conveying Form
Drive by two sides conveying belts
Dimension (L×W×H) (mm)
1755×800×(960 to 1650)
Net Weight (kg)
150
Maximum Outside Diameter of
Adhesive Tape (mm)
250
1.3 Product feature
This machine is very convenient to use. After adjusting the size of the sealing box, the device
can complete the sealing action only by pushing the carton in.
Seal box size adjustment range is wide, suitable for various specifications of carton
packaging.
1.4 Working principle
After folding the carton blades, the carton is pushed into the sealing machine, driven by
parts up and down, and the carton is sealed by the upper and lower sealing head mechanism.
