Je bekijkt pagina 31 van 34
Item Part number Quantity Description Remark
5-1 1
M10 hexagon nut M10
5-2 521323 1
washer
5-3 936411.6-1414 1
small pressure spring
5-4
521322
1
mandrel
5-5 1
tape roller
5-6 521325 1
tape roll shaft
5-7 521321 1
tape roll plate
5-8 2
clamp plate assembly
bilateral
symmetry
5-9 2
6001-2Z bearing 12X28X8
5-10 2
M6 sunk screw
5-11 2
tension bolt
M6X1 full
thread
5-12 521317 1
front mounting block assembly
5-13 6
M6 hexagon flange nut M6
5-14 521303 1
front shaft
5-15 521304 2
front roller
5-16 910741-12B 2
1565X50 conveyor belt black
5-17 935601-01 2
6001-2Z bearing
12X28X8
5-18 521314 1
bottom reducer holder assembly
5-19 521307 22
transmission roller
5-20 521308 14
shaft of transmission roller
5-21 921032 1
speed reducer
5RK90GU-CF1
5GS15-K
5-22 521309 2
rear roller
5-23 521305 1
rear shaft
5-24 2
circlip for shaft 17
5-25 2
6003-2Z bearing 17X35X10
5-26
（same as item 5-19）
5-27 1
rear mounting block
5-28 521306 2
end cover of rear shaft
5-29 2
set collar of middle shaft
5-30 521310 2
middle shaft
5-31 521301 1
brush-retaining bracket
5-32 1
cover of bottom reducer
5-33 521320 1
sprocket of upper motor（Z=14）
