Item Part number Quantity Description Remark
4-1 521203 2
width knob
4-2 521204-2 2
pin
4-3 521512 2
upper guide wheel shaft assembly
4-4 521504 2
guide nylon wheel
4-5 2
tension bolt M6 full thread
4-6 521503 1
long rod
4-7 6
M6 flange nut
4-8 521304 2
front roller
4-9 521303 1
front shaft
4-10 1
flap fold sheet
4-11 2
bolt
4-12 521507 2
guide rod
4-13 1
front clamp plate assembly
4-14 935601-01 2
6001-28 bearing 12X28X8
4-15 1
front cover plate
4-16 1
hexagon nut M18X1.5
4-17 521321 1
tape roll plate
4-18 521325 1
tape roll shaft
4-19
521322
1
tape roller assembly
4-20 1
mandrel
4-21 936411.6-14.4 1
small pressure spring
4-22 521323 1
small washer
4-23 1
hexagon nut M10
4-24 F52101-3 1 set
upper tape head assembly
4-25 921032 1
reducing motor
5RK90GU-CF
15GS15-K
4-26 521320 1
sprocket of upper motor
4-27 1
upper reducer cover
4-28 1
upper reducer holder
4-29 2
clamp plate assembly
bilateral
symmetry
4-30 521305 1
rear shaft
4-31 521301 1
brush-retaining bracket
4-32 521302 1
sprocket（Z=15）
4-33 910741-11B 2
transmission belt
1368X50 conveyor belt
black
4-34 2
6003-2Z bearing 17X35X10
4-35 521309 2
rear roller
4-36 2
cover of upper transmission belt
bilateral
symmetry
4-37 2
Ф6 washer Ф8
