Item Part number Quantity Description Remark
2-1 521019 2
clamp plate assembly
bilateral
symmetry
2-2 935600-8 2
628/8-2Z bearing
8X16X5
2-3 521007 2
jam nut
2-4 521008 2
cover
2-5
2
Ф10 circlip for shaft
2-6 521020 1
tension spring shaft
2-7 521009 1
tension spring housing
2-8 521021 1
shaft sleeve of rear plate
2-9 521006 1
chord axis
2-10 521034 2
small backing plate
bilateral
symmetry
2-11 1
iron core of rear rubber roller
2-12 521005 2
shaft
2-13 521024 1
rear rubber roller
2-14 2
M6X10 sunk screw
2-15 521022 2
C-shaped plate assembly
bilateral
symmetry
2-16 910631-01 2
shaft sleeve
2-17 521041 1
shaft
2-18 521037 1
backup plate
2-19 936430.8-11 1
torsional spring
2-20 521042 1
flange
2-21 521044 1
plate for torsional spring
2-22 936431-11 1
torsional spring
2-23 1
HF1012 unilateral bearing
2-24 910631-02 1
bush
2-25 521023 1
front rubber roller
2-26 521041 1
iron core of front rubber roller
2-27 1
M5X10 sunk screw
2-28 1
2-29 1
2-30 1
2-31 6
Note：Item 27 and 29 are welded together.
Item 11 and 13 are welded together.
