CBS- 880 INSTRUCTION MANUAL
39
Figure 45. Conveyor Table
Item Part # Description Quantity Comments
1
CBS-880-1 conveyor belt 1
2
BS-16 adjusting block for conveyor belt 2
Includes #2, 3, 4
3
BS-16 double end bolt 2
Includes #2, 3, 4
4
BS-16 adjusting knob for conveyor table 2
Includes #2, 3, 4
5
CBS-880-41 6201-Z bearing 3
Includes #5, 14-18
6
CBS-880-36 bearing seat of rear roller 2
Includes #5, 6, 7, 8
7
CBS-880-36 rear shaft of conveyor table 1
Includes #5, 6, 7, 8
8
CBS-880-36 rear roller of conveyor table 1
Includes #5, 6, 7, 8
9
CBS-880-18 / CBS-880-18B half-round square neck bolt 2
Includes #9, 11, 12
10
CBS-880-15 worktable 1
specify flat or curved edges
11
CBS-880-18 plastic spacer 2
Includes #9, 11, 12
12
CBS-880-18 / BS-17 knob 2
I
ncludes #9, 11, 12
13
CBS-880-20 conveyor table 1
14
CBS-880-41 bearing seat 1
Includes #5, 14-18
15
CBS-880-41 middle shaft of conveyor table 1
Includes #5, 14-18
16
CBS-880-41a sprocket of conveyor table 2
Includes #5, 14-18
17
CBS-880-41 bearing seat (three-hole) 1
I
ncludes #5, 14-18
18
CBS-880-41 6001-2Z bearing 1
I
ncludes #5, 14-18
19
CBS-880-37 two-eye bearing seat 2
Includes #19, 20, 21, 22
20
CBS-880-37 front roller of conveyor table 2
Includes #19, 20, 21, 22
21
CBS-880-37 front shaft of conveyor table 1
Includes #19, 20, 21, 22
22
CBS-880-37 6201-2Z bearing 2
I
ncludes #19, 20, 21, 22
23
CBS-880-38 chain (48 segments) 1
