Enterprise Storage Manager Software User Guide Rev. A 18
www.seagate.com Chapter 3: Server View
The following table describes the components in the Server Summary page.
CALLOUT DESCRIPTION
1 Left tab panel: Contains tabs that help you to navigate to the following pages in the Server view:
: Server Summary page (the current page, the default page).
: Server Deep Dive page, which lets you monitor the host performance.
: Server Events, which lets you monitor the device activities in the form of event messages.
NOTE The Performance Collection Management page lets you enable or disable the performance collection
on the Nytro cards.The Performance Collection Management tab appears only if the host has at least one
Nytro card and if the Nytro card supports performance monitoring.
2 Breadcrumb navigation – Helps you to traverse between the various views. For example, you can traverse
from the Server view to any of the Nytro products view. The breadcrumbs provide a trail for you to follow
back to the starting point or the entry point. It also shows the title and the status icon for every device that
you are viewing.
3 Displays the name of the user.
4 Toolbar – The description follows:
: Lists the managed servers that you are monitoring. The list lets you switch to any server.
The color-coded icons (red and green) indicate the consolidated status of all the Seagate Nytro
Application Accelerated products that are connected to the server. If one of the products is down, the
consolidated status appears as red.
: Indicates the consolidated number of unread global alerts for all of the servers and devices that
are monitored. Click the alert icon to view the servers that are monitored and the corresponding
number of unread alerts for each server. You can select a server and navigate directly to the Server Events
page to view the events that occurred on that server.
: Lets you perform the following tasks:
— : Add managed hosts, edit managed host credentials, and remove the managed hosts.
— : Set up email accounts and event notifications.
— : Set up the email server.
— : Get information about the Enterprise Storage Manager software.
— : View all of the physical components that are attached to the cards and their firmware, driver, or
library details.
For more information about performing these tasks, see Section 2, Performing the Initial Setup.
: Enterprise Storage Manager software context-sensitive help.
: Exit from the Enterprise Storage Manager software.
5 Server Summary: Briefly summarizes all of the server configurations, such as the operating system version,
operating system architecture, host memory size, and number of CPU cores that are connected to the host.
6 Server Storage: Shows the used and unused space information for all of the cache volumes and the virtual
drives that the SSDs create. It also shows the configured and unconfigured storage capacity of the drives.
7 Seagate Nytro Application Acceleration Products: Shows the configuration details of all of the Seagate
Nytro products that are connected to the server.
NOTE Click any of the Seagate Nytro products to navigate to its specific view.
