OneStor® SP-3584 Installation & User Guide
4
All power supply cords must have a safe electrical ground connection. Check the connection to ground
of the enclosure before you switch on the power supply.
Important The enclosure must be grounded before applying power.
The plug on the power supply cord is used as the main disconnect device. Ensure that the socket outlets
are located near the equipment and are easily accessible.
Warning When powered by multiple AC sources, disconnect all supply power for complete isolation.
Warning Do not remove covers from the enclosure or any of the modules – there is a danger of electric
shock inside. Do not attempt to disassemble the rear sub-chassis from the enclosure. Return any
damaged components to your supplier for repair.
Caution The PSUs contain double pole/neutral fusing. Ensure that your electrical installation can support this.
Important The optional RJ45 socket on the I/O module is for Ethernet connection only and must not be
connected to a telecommunications network.
1.6 Rack System Safety Precautions
The enclosure must be mounted in a rack before use.
The rack must be capable of supporting the total weight of the installed enclosure(s). A fully populated
enclosure weighs up to 135kg (298lb). The design should incorporate stabilizing features suitable to
prevent the rack from tipping or being pushed over during installation or in normal use.
When loading a rack with enclosures, fill the rack from the bottom up. When removing enclosures,
empty from the top down.
Warning The enclosure must only be mounted into a rack using the supplied rail kit. Due to its weight and length,
the enclosure must not be flange mounted.
Before mounting the enclosure, remove all DDIC modules from both drawers and make sure the drawers
are closed firmly and locked shut. Do not try to lift the enclosure by yourself (see section
1.3, “Handling”, on page 1).
Warning Never move more than one enclosure out of the rack at any one time: there is a danger of the rack
falling over.
