UF0915X, UF1415X, UF2020X, UN0815X, UN1215X, and UN1520X User Manual
March 2024
Page 4
Remove all shipping and packing materials that may
be in the ice storage bin.
The unit can be installed with or without legs. The
cabinet is equipped with small bumpers on the base
to allow placement without legs.
An optional oor mounting kit is also available to ll
the gap between the machine and oor if not using
legs.
If using legs, carefully tip the machine and install
the legs by screwing them into the leg sockets in the
bottom of the machine. For reference, the thread size
is 5/8-11.
If the machine has been tipped onto its side or back
allow 1 hour before starting the unit for the oil in the
refrigeration system to return to the compressor.
Place the machine in its intended location and level it
front to back and left to right. If using legs, adjust their
feet in and out to level the cabinet.
If legs are not used the bottom edges of the cabinet
must be sealed to the oor to pass most codes.
If built into a cabinet, the adjacent cabinet walls will
provide the means for containment. There are no
means for attachment to the cabinet.
Be sure to remove the plastic covering the exterior
panels, if left on it will be much harder to remove
later.
Location of Dataplate
Model and Serial plate with
QR code located behind
front panel.
Unpacking and Setup
Model
and Serial
Number
Dataplate
