Product Information
The product is a modular cuber. That type of
machine is designed to be placed on an ice storage
bin or an ice dispenser. Many installations only
require the matching bin, but some also require an
adapter to be placed between the bin and the
cuber or between the dispenser and the cuber.
This product cannot be stacked. See the chart
for application information.
Model Number Description
Example:
•
C1448MA-6A
•
C= cuber
•
14= nominal ice capacity in 100s of pounds
•
48= nominal width of cabinet
•
S= Cube size. S=small or half dice cube.
M=medium or full dice cube
•
A=Condenser type. A=air cooled. W=water
cooled
•
-6=230/50/1
•
A=Series revision code. A=first series
Note: In some areas of this manual model numbers
may include only the first five characters of the
model number, meaning that the cube size,
condenser type and voltage differences are not
critical to the information listed there.
Options:
There are several field-installed options that can be
installed at initial start up or later. They include:
•
Vari-Smartä adjustable ice level system.
•
SmartBoardä advanced feature control.
Some installations require bin adapters. See the
table below.
Standard Bin Applications - Adapter
information.
Model BH900*, B948S
BH1100,
BH1300,
BH1600
C1448,
C1848,
C2148
Direct Fit, no
adapter needed
No adapter
needed
* Note. If previously equipped with stainless steel
baffle, KBAFFLE3, remove and replace with
original plastic baffle.
Other Bins & Applications:
Note the drop zone and ultrasonic sensor locations
in the illustrations.
Scotsman assumes no liability of responsibility of
any kind for products manufactured by Scotsman
that have been altered in any way, including the
use of any part and/or other components not
specifically approved by Scotsman.
Scotsman reserves the right to make design
changes and/or improvements at any time.
Specifications and design are subject to change
without notice.
November 2006
Page 3
C1448, C1848, C2148W
Air and Water Cooled User Manual
