MC1448 and MC1848

Air and Water Cooled User Manual

June 2022

Page 2

Airow

Installation: Product Specications

Location Limitations:

The product is designed to be installed indoors, in a

controlled environment. Air cooled models discharge

very warm air into the room out the back. Space must

be allowed at the sides and back for air discharge.

Water cooled models discharge warm water into the

building’s drain.

Space needs to be provided on both sides and above

for service access.

Space Limitations

Note: Although the machine will function, ice capacity

of air cooled machines will be signicantly reduced

with minimal clearance at the sides, back and top.

Some space is recommended for service and

maintenance purposes on all models.

6" of space at the sides and back are required for

adequate operation. To get the most capacity, locate

the machine away from heat producing appliances

and heating ducts, and allow 12-18 inches of space

at the sides and top for good air ow.

Airow enters through the front and left and exits

the back. Attach a ba󰀪e kit to the back when an air

cooled unit is installed with minimal side and top

clearance. See the next page for kit numbers.

Environmental Limitations

Minimum Maximum

Air temperature 50

F. 100

Water temperature 40

F. 100

Water pressure 20 psi 80 psi

Power supply – acceptable voltage ranges

Minimum Maximum

208-230 volt model 198 volts 253 volts

Warranty Information

The warranty statement for this product is provided

separately from this manual. Refer to it for applicable

coverage. In general warranty covers defects

in material or workmanship. It does not cover

maintenance, corrections to installations, or situations

when the machine is operated in circumstances that

exceed the limitations printed above.

Product Information

This product is a modular cuber. This type of machine

is designed to be placed on an ice storage bin or

an ice dispenser. Many installations only require the

matching bin, but some also require an adapter to

be placed between the bin and the cuber or between

the dispenser and the cuber. This product cannot be

stacked.

See the chart on the next page for application

information.
