MC0322 through MC1030

Air and Water Cooled User Manual

June 2022

Page 3

Model Number Description

Example:

• MC0322SA-1A

• MC= modular cuber

• 03= nominal ice capacity in 100s of pounds

• 22= nominal width of cabinet

• S= Cube size. S=small or half dice cube.

M=medium or full dice cube

• A=Condenser type. A=air cooled. W=water cooled

• -1=115 60 Hz, -32=208-230 60 Hz, -3= 208-230 3

phase 60 Hz

• A=Series revision code.

Note: Listed model numbers typically include only the

rst ve characters of the model number.

Options:

There are several eld-installed options that can be

installed at initial start up or later. They include:

• KVS, Vari-Smart Adjustable ice level system.

• KBILC, Basic Ice Level Control

• KSB, SmartBoard Advanced feature board.

• Side Air Flow Kits:

• PPSA223 (MC0322, MC0522)

• KPPSA22, (MC0722)

• KPPSA323 (MC0330, MC0530, MC0630)

• KPPSA329 (MC0830, MC1030)

• Some installations require bin or dispenser

adapters, see following tables for specic

applications.

Standard Bin Applications - Adapter information.

Model B222

B322

B530P,

B330P,

B530S,

B842S B948S

MC0322,

MC0522,

MC0722

Direct t KBT27 Not

available

Not

available

MC0530,

MC0630,

MC0830,

MC1030

Does not

t

Direct t KBT28 KBT22

Hotel Dispensers

The HD22 and HD30 are compatible with this ice

machine, no adapters are needed. Some typical

combinations include:

• HD22 – use with MC0322 or MC0522

• HD30 – use with MC0330 or MC0530

Ice and Beverage Dispensers – Adapter

information

Model ID150 ID200 or ID250

MC0322,

MC0522,

MC0722

KBT42 KBT43

MC0530,

MC0630,

MC0830,

MC1030

Does not t KBT44

Other Bins & Applications:

Note the drop zone and ice level control sensor

locations in the illustrations on the next pages. A bin

or dispenser top must accommodate their locations.

See sales literature for additional applications and

specialized kits.

Scotsman Ice Systems are designed and

manufactured with the highest regard for safety and

performance.

Scotsman assumes no liability of responsibility of

any kind for products manufactured by Scotsman

that have been altered in any way, including the use

of any part and/or other components not specically

approved by Scotsman.

Scotsman reserves the right to make design changes

and/or improvements at any time. Specications and

design are subject to change without notice.
