HID312AWX, HID525AWX and HID540AWX
Installation and User’s Manual
January 2025
Page 17
Sanitize now.
20. Mix a 2 gallon solution of sanitizer. A
recommended sanitizer solution is one 2 oz.
packet of Stera Sheen Green Label and 2 gallons
of warm (95
o
to 105
o
F.) potable water, or an
equivalent sanitizer at a concentration of 100 ppm.
21. Pour the sanitizer solution into the reservoir until it
is full (level with the molded line on the side).
22. Reconnect electrical power.
23. Push the ON/OFF button to make ice for 10
minutes. Add more sanitizer to the reservoir to
keep it full while making ice.
24. Push the ON/OFF button to stop making ice.
25. Disconnect electrical power.
26. Remove the ice outlet cover, dispense rotor and
ice dispenser agitator from the bin. Wash them
with the sanitizer solution.
27. Wash all inside surfaces of the ice storage bin and
ice discharge chute with the sanitizer solution.
28. Wash the ice discharge chute cover, ice sweep,
metal area below the ice sweep and ice dispense
chute with the sanitizer solution.
29. Pour remaining sanitizer into the bin and sink. Do
not overll bin.
30. Drain sanitizer from ice making system by pulling
reservoir drain hose from plug and return hose to
plug when drained.
31. Loosen thumb screw holding water reservoir to
post and lower the water reservoir to the top of the
slot, retighten thumb screw.
32. Return the chute cover, dispense rotor and
agitator to the inside of the storage bin. Secure
with the original fasteners.
33. Return the ice dispense chute and water reservoir
cover to their original positions and secure them
with their original fasteners.
34. Reconnect water and electrical power to the
machine.
35. Push the ON/OFF button to restart ice making.
36. Operate machine for 5 minutes and then push the
ON/OFF button to stop ice making.
37. Pour 16 oz of warm (95
o
to 105
o
F.) potable water
into the bin. Repeat until the ice has been melted.
38. Return the dispense bin cover to the machine and
secure with the original screws.
39. Push the ON/OFF button to resume ice making.
40. Return all panels to their normal positions and
secure with the original screws.
Other maintenance
The auger in the ice making system is centered by
bearings at the top and bottom. It is also sealed from
leaking by a water seal at the bottom.
The bearings are permanently lubricated and need
no maintenance. They can be visually checked for
obvious wear or damage but there is no need to add
lubrication.
Auger motor bearings and the gear reducer are also
permanently lubricated and need no maintenance.
The bottom of the ice making system should be
checked for water leaks. Water draining from
the bottom is an indication of a water seal leak.
Immediate repair is required when a water seal leak is
discovered.
Caution: Moving parts hazard. Do not touch the
rotating shaft at any time.
Rotating Shaft -
Do NOT Touch
Bearing
