HID312AWX, HID525AWX and HID540AWX
Installation and User’s Manual
January 2025
Page 13
Maintenance and Cleaning
There are ve areas of maintenance:
1. Drain system
2. Air cooled condenser lter and condenser
3. Ice dispense bin and rotor
4. Photo eye ice level control
5. Ice making water system
Drain System
1. Remove upper front panel.
2. Twist dispense chutes clockwise and pull down to
remove.
3. Push in dispense disable switch, remove screws
holding lower front panel to unit and unplug lower
panel sensors at the harness connection. Set
panels aside.
4. Shut the machine o.
5. Pour hot water into the drain basin to conrm free
drainage.
6. Clean the dispense chutes. Use ice machine scale
remover if needed to dissolve scale.
7. Reverse to reassemble. Insert chutes and rotate
CCW until they snap into place and stop.
Air lter
The air lter on the left side of the cabinet will capture
signicant dust and lint during operation. As the dirt
builds up it begins to restrict air ow and causes the
refrigeration system to work longer to make ice. Clean
the air lter regularly.
To remove, pull it forward from the louvers. Do not
leave it out for extended periods of time.
To clean, wash it at a utility sink. Return it to the unit
when clean.
Condenser.
The condenser ns may need cleaning too. Remove
the left side air grill and brush any lint and dirt o the
surface of the condenser. Vacuum any remaining
dirt. Do not damage the ns of the condenser during
cleaning.
