User Manual for Models CUR0415, CUR0715 and CUR0920
July 2013
Page 8
Connect the power
This is a cord-connected unit, and must be connected
to its own dedicated power supply. Check the
dataplate on the back of the machine for the proper
voltage and per the dataplate use fuses or HACR
circuit breakers.
Power Cords:
230 volt, 60 Hz models are equipped with a 14136
power cord and plug.
Note: In case the power cord is damaged, it
must be replaced by a like cord. Replacement
cords are available from the manufacturer’s local
representative. Replacement should only be done
by a qualied technician to prevent possible risks.
The power cord plug will be the disconnect means for
the machine and must be accessible when the unit is
in its permanent location.
Follow All Local Codes - This Unit Must Be
Grounded. Do not use extension cords and do not
disable or by-pass ground prong on electrical plug.
Plug the power cord into the power supply.
Installation check list
• Has the machine been installed indoors in an
environment suitable for it?
• Have all of the shipping items and packaging been
removed?
• Is the ice chute in the correct position?
• Is the clear plastic curtain hanging down and free to
move?
• Has the water supply been connected and
conrmedtonotleak?
• Has a properly sized and sloped drain tube been
attached?
• Has the correct voltage power supply been
connected?
Front view of freezing compartment, right arrow points
to clear plastic curtain. It must hang freely. Left arrow
pointstoCubeDeector,itmustbepositionedas
shown.
Front view of freezing compartment, shown without
Ice Chute or Curtain. Right arrow points to Spray
Platform, located under Ice Chute. Spray Platform
inlet connects to pump hose and is snapped into clip
at back of reservoir. Left arrow points to clip.
