January 2025
Page 11
User Manual for Models CU0415X, CU0715X and CU0920X
Use and Operational Notes
To use, simply lift the door by its bottom edge and
slide it up and into the top of the machine. Use the
scoop to remove ice, then close the door when
nished.
The machine will make the most ice if it has plenty
of room to breathe. This is an air cooled product
and it must be able to take in room temperature air
and discharge air heated by the ice making process.
Blockage of vents or exposure to excessive heat
will reduce the ice making and storage capacity of
the machine. The storage bin is insulated but not
refrigerated, so ice will melt during use. That is normal
and assures that fresh ice is available in the bin.
The fan will make some noise during operation.
However, rattles and other vibrations are not normal
and should be attended to. When the air temperature
surrounding the machine is cold, the fan might cycle
on and o during the freeze mode.
If the machine is in a space colder than the minimums
listed, it will not switch on to make ice.
Minor adjustments may be made to compensate for
local conditions by rotating the adjustment screw
which is visible above the control area. If in a cold
room, CW rotation changes the control to COLDER to
ll the bin higher.
If installed at an altitude greater than 2000 ft or 610
meters above sea level, the bin thermostat may need
internal adjustment. The adjustment screw is behind
the front of the control, accessed through a hole for it.
Bin Thermostat Altitude Adjustment Table:
Altitude (ft) Altitude (meters) Degree of
adjustment
2000 600 31 CW
3000 900 52 CW
4000 1200 72 CW
5000 1500 92 CW
6000 1800 111 CW
7000 2100 128 CW
No Step
Do not stand on the machine.
Severe damage can occur.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
Typical Full Bin
