3 Electrical heat - (IP20)
Model Output
(kW)
Airflow*
1
(CFM)
Sound power*
2
(dB(A))
FLA (full load
amperage)*
3
(A)
Motor
power
(W)
Amperage
motor
(A)
Voltage (V)
Amperage (A)
(heat)
Weight
(lb)
AC-KE36-20 2.7/4.1 859 70 7.1 80 0.6 208V3~/6.5
AC-KE36-48 3.3/5 859 70 6.6 80 0.6 480V3~/6.0
AC-KE36-60 3.3/5 859 70 5.2 80 0.6 600V3~/4.8
AC-KE60-20 3.2/6.5 1592 72 11.3 110 0.9 208V3~10.4
AC-KE60-48 4/8 1592 72 10.5 110 0.9 480V3~/9.6
AC-KE60-60 4/8 1592 72 8.6 110 0.9 600V3~/7.7
AC-KE72-20 4.1/8.1 1875 73 14 140 1.0 208V3~/13
AC-KE72-48 5/10 1875 73 13 140 1.0 480V3~/12
AC-KE72-60 5/10 1875 73 10.6 140 1.0 600V3~/9.6
1 Ambient, no heat - (IP21)
Model Output
(kW)
Airflow*
1
(CFM)
Sound power*
2
(dB(A))
Motor
power (W)
Voltage
motor (V)
Amperage
motor (A)
Weight (lb)
AC-KA36-23 0 859 70 80 208V~ 0.6 35
AC-KA60-23 0 1592 72 110 208V~ 0.9 53
AC-KA72-23 0 1875 73 140 208V~ 1.0 71
1. Highest airflow at 3 fan speed.
2. Values shown are for total sound power levels for Installation Type A: free inlet, free outlet.
The Sound power level ratings shown are in decibels, referred to 10-12 watts, calculated per AMCA
Standard 301.
3. FLA: total amperage for motor and heat.
Above table is valid for 208V/1ph/60Hz. Also approved for 230V/1ph/60Hz. Product performance for
230V/1ph/60Hz will differ from stated data.
Protection class for units with electrical heating: IP20.
Protection class for units without electric heating: IP21.
Technical Specification
AC KE 72 60
Select10 Series
Electric Heated
Air Curtain
Nominal Length of unit
in inch
Voltage Code 600V
37.5
42
42
57.3
61.7
61.7
75
79.3
79.3
