- 5 - EN
6. OPERATING INSTRUCTIONS
6.1 To start a vehicle
IMPORTANT:
- Using the booster without a battery installed in the vehicle will damage the vehicle’s
electricalsystem.
- Only jump start a 12 V lead-acid battery system vehicle.
- Only use the smart cable provided with the product for the jump start function.
NOTE: The internal battery must have a charge if at least 75% to jump start a vehicle.
Ignite OFF and all electrical devices (heating, lighting…) before using the booster.
Lay the DC cables away from any fan blades, belts, pulleys and other moving parts.
1. Connection to the booster - Stand-by mode
Plug the battery clamps smart cable into the booster’s output socket. The green LED is
ashing on the smart cable, which means that the booster is in “Jump Start Stand-by mode”.
2. Connection to the battery
Check rst if the negative terminal is connected/grounded to the chassis. If not, contact
your reseller.
Connect the red clamp (+) to the positive terminal (+) of the battery, then connect
theblack clamp (-) to the earth/chassis of the vehicle (a heavy gauge metal part of the
frame or engine block. Do not connect to the carburetor or fuel lines).
3. Jump Start mode
The green LED on the smart cable turn into solid green, which means that the booster
isin“Ready to Jump Start mode”.
NOTE: If the vehicle battery is extremely discharged, the initial current draw from the
booster may activate short circuit protection in the smart cable. When the condition
iscorrected, the smart cable will automatically reset.
4. Start the engine
Crank the engine for maximum 3 seconds and wait at least 1 minute before a second
attempt.
5. Disconnect the output cable
After the engine starts, unplug the battery clamps from the booster socket.
6. Disconnection
Disconnect the black clamp (-) at rst and then the red clamp (+).
7. Recharging
Recharge the unit as soon as possible.
6.2 Starting attempt
When using the booster to start an engine, do not crank for more than 3 seconds, and wait
atleast 1 minute before a second attempt.
If the car does not crank a second time, check the smart cable to see if the green LED is lit
(solid). If you hear beeping or an LED is ashing, refer to Troubleshooting.
NOTE: Cold weather may aect the performance of the booster’s lithium battery. If you hear
only a click and the engine does not turn over, try the following:
With the booster connected to the car battery and the green LED solid on the smart cable, turn
on all lights and electrical accessories for one minute. This draws current from the booster and
warms the battery. Now try to crank the engine. If it does not turn over, repeat the procedure.
Extremely cold weather may require two or three battery warmings before the engine will start.
IMPORTANT: DO NOT attempt to jump start your vehicle more than three consecutive times.
Ifthe vehicle will not start after three attempts, consult a service technician.
