- 4 -EN
Using acharger with less than 2 A will increase charge time.
1. Plug the USB-C end of the charging cable into the input port. Next, plug the USB end
of the charging cable into a charger’s USB port.
2. Plug your charger into a live AC or DC power outlet.
3. When the battery is fully charged, disconnect your charger from the outlet, and then
remove the charging cable from the charger and the unit.
4. USING THE LED LIGHT
1. Press the power level button.
2. Hold down the power level button for 3 seconds.
3. Once the LED light is on, press and release the display button to cycle through the
following modes:
- Steady glow;
- Flash for an SOS signal;
- Flash in strobe mode
4. When nished using the LED light, press and hold the power level button until the light
turns o.
5. Recharge the unit as soon as possible after each use.
5. CHARGING A MOBILE DEVICE WITH THE USB PORT
The USB port provides up to 2.4 A at 5 V DC.
1. Plug a charging cable into the input port of your mobile device. Then plug the USB end
of the charging cable into the booster USB port.
2. Charging should start after pressing power button.
3. Charging time will vary, based on the mobile device battery size.
4. When nished using the USB port, disconnect the charging cable from your mobile
device and then disconnect the charging cable from the unit.
5. Recharge the unit as soon as possible after each use.
NOTE: If no USB device is connected, power to the USB ports will automatically shut o after
30 seconds.
6. OPERATING INSTRUCTIONS
6.1 To start a vehicle
IMPORTANT:
- Using the booster without a battery installed in the vehicle will damage the vehicle’s electrical
system.
- Only jump start a 12 V lead-acid battery system vehicle.
- Only use the smart cable provided with the product for the jump start function.
NOTE: The internal battery must have a charge if at least 50% to jump start a vehicle.
Ignite OFF and all electrical devices (heating, lighting…) before using the booster.
Lay the DC cables away from any fan blades, belts, pulleys and other moving parts.
1. Connection to the booster - Stand-by mode
Plug the battery clamps smart cable into the booster’s output socket. The green LED
isashing on the smart cable, which means that the booster is in “Jump Start Stand-
bymode”.
2. Connection to the battery
Check rst if the negative terminal is connected/grounded to the chassis. If not, contact
your reseller.
Connect the red clamp (+) to the positive terminal (+) of the battery, then connect the
black clamp (-) to the earth/chassis of the vehicle (a heavy gauge metal part of the frame
or engine block. Do not connect to the carburetor or fuel lines).
