www.scheppach.com
26
|
GB
10. Attachment and operation
m Attention!
Always make sure the device is fully assembled
before commissioning!
You require the following for assembly:
• 2 x open-ended spanner 14 mm (not included in the
scope of delivery)
10.1 Fitting the wheels (g. 6, 7)
• Screw 1 nut (B) onto the thread of the wheels (3)
supplied.
• Then fasten the wheels (3) to the wheel brackets at
the bottom of the pressure vessel (2) by holding the
nut (B) on the wheel (3) in place with an open-ended
wrench and tightening the ange nut (D).
10.2 Installing the supporting foot (g. 5)
• Fit the supplied supporting foot (4) with 2 hexagon
screws (A), 2 washers (C) and 2 ange nuts (D) as
shown in g. 5.
10.3 Mains power connection
• The compressor is equipped with a mains cable
with protective contact plug. This can be connected
to any 230 V~ / 50 Hz protective contact socket, with
fuse protection of at least 16 A.
• Before commissioning, ensure that the mains volt-
age matches with the operating voltage and the ma-
chine’s power rating on the type plate.
• Long supply cables, extensions, cable reels, etc.
cause a drop in voltage and can impede motor start-
up.
• In the case of temperatures below +5°C, motor
starting can be endangered by sluggishness.
10.4 ON/OFF switch (g. 2)
• The compressor is switched on by setting the switch
(8) to position I.
• The compressor is switched o by setting the switch
(8) to position 0.
10.5 Pressure adjustment (g. 2)
• The pressure at the pressure gauge (6) can be ad-
justed with the pressure regulator (7).
• The pressure set can be drawn from the quick cou-
pling (5).
8. Unpacking
• Open the packaging and carefully remove the device.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating instructions before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
m ATTENTION!
The device and the packaging material are not
children’s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
9. Before commissioning
• Before connecting the machine, make certain that
the data on the type plate matches with the mains
power data.
• Check the device for transport damage. Report
any damage immediately to the transport company
which was used to deliver the compressor.
• Install the compressor near the point of consumption.
• Avoid long air lines and supply lines (extension cables).
• Make sure that the intake air is dry and free of dust.
• Do not deploy the compressor in damp or wet areas.
• Operate the compressor only in suitable areas (well
ventilated, ambient temperature +5°C to 40°C).
There must be no dust, acids, vapours, explosive
gases or inammable gases in the room.
• The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor in are-
as where work is conducted with sprayed water.
• The compressor may only be used outdoors briey
when the ambient conditions are dry.
• The compressor must always be kept dry and must
not be left outdoors after work is complete.
