Table of contents
1 Introduction ........................................................ 19
2 Product description (Fig. 1-15)........................... 19
3 Scope of delivery (Fig. 2) ................................... 20
4 Proper use.......................................................... 20
5 Safety instructions.............................................. 20
6 Technical data.................................................... 21
7 Unpacking .......................................................... 21
8 Assembly............................................................ 21
9 Operation ........................................................... 23
10 Working instructions........................................... 23
11 Cleaning and maintenance ................................ 24
12 Storage and transport ........................................ 25
13 Electrical connection .......................................... 25
14 Repair and ordering spare parts ........................ 26
15 Troubleshooting ................................................. 26
16 Disposal and recycling ....................................... 27
17 EU Declaration of Conformity............................. 28
18 Exploded view.................................................... 99
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
The product complies with the applicable
European directives.
The product complies with the applicable
Serbian directives.
1 Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws, the
manufacturer of this product assumes no liability for dam-
age to the product or caused by the product arising from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE0113 not being observed.
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instructions
before using the product. Only operate the product as de-
scribed and for the specified areas of application. Keep the
operating manual in a good place and hand over all docu-
ments when passing the product on to third parties.
2 Product description (Fig. 1-15)
1. Transport handle
2. Carrying handle
3. Container cover
3a. Holder
4. Container
4a. Locking mechanisms
5. Drain hose
5a. Drain plug
6. Wheels
7. Base frame
7a. Holders
8. Castors
9. Suction connection
9a. Fitting port
10. Product socket outlet
11. On/off switch
12. Blast connection
13. Filter cage
13a. Safety float valve
13b. Self-cleaning lever
14. Vacuum hose
14a. Hose coupling
15. Handle
15a. Slider
16. Telescopic tube
16a. Release button
17. Floor nozzle
18. Suction adapter
19. Joint nozzle
20. Paper filter bag
20a. Sealing ring
21. Foam filter
22. Filter cartridge
23. Screw
GB | 19www.scheppach.com
