GB І 19

• Only ever plug the machine into an appropriately

installed shockproof socket which is fused with at

least 16 A.

Setup

Warning! Disconnect the plug before all maintenance,

retooling and assembly work on the weed killer.

Place all supplied parts on a at surface. Group the

same parts.

Handle assembly (Fig. 2)

1. Loosely screw the compression ttings (5) on the

designated threads.

2. Firmly attach the handle (6).

3. Tighten the compression tting (5).

Assembly of lance with hose (Fig. 3)

1. Screw the lance (9) together with the hose (25).

Operation

Filling with water (Fig. 4)

1. Remove sealing cap (4) as shown in Fig. 4.

2. Fill a maximum of 20L of water using a suitable

container or funnel. Use pure rainwater or distilled

water, if applicable, because it will not cause calci-

cation.

3. Wipe up spilled water with a dry towel immediately.

4. Fit the sealing cap and tighten as shown in Fig. 4.

Mains connection (Fig. 5)

1. Open the sealing cap of the spray-water-protected

mains plug (3).

2. Connect the mains plug (3) with extension cable

(11) to the mains.

Heating mode (Fig. 6/8)

1. Switching on: Press the ON/OFF button (14) once

- A beep sound is issued. The operation LED (15)

begins to illuminate. The water temperature is dis-

played on the temperature indicator (17). If there

is too little water in the system, the water shortage

warning LED (16) illuminates.

2. If there are leaks in the water system, switch off the

device immediately with the ON/OFF button (14)

and disconnect the device from the mains with the

mains connection cable. There is a risk of electric

shock!

3. Heating the water: Press the heating button (21)

and the water in the tank is heated up. The current

water temperature can be seen on the temperature

indicator (17). Depending on the lling temperature

of the water, it can take up to 45 minutes before the

water has been heated up to maximum tempera-

ture.

4. When the maximum temperature is reached, three

short beeps are issued and the LED for heating

mode (22) goes out.

Check the cable for damage.

• Remove the plug from the socket before all work

on the machine, before rest periods and when the

machine is not being used.

• Mains cables may not have a smaller cross section

than 2 x1.5 mm².

• Charge the batteries only in chargers that have

been recommended by the manufacturer. There is

a risk of re if a charger for a particular type of bat-

tery is used for another type of battery.

• Use only the designated type of battery in the pow-

er tool. Use of other batteries can cause injury and

re.

• While the battery is not being used, keep it away

from paperclips, coins, keys, nails, screws and oth-

er small metal objects which could bridge the con-

tacts. A short-circuit between the battery contacts

can cause burns or re.

• If used incorrectly, liquid may leak from the battery.

Avoid contact with it. In the event of accidental con-

tact, rinse with water. If the liquid gets in your eyes,

also consult your doctor. Leaking battery liquid can

cause skin irritation and burns.

• WARNING! RISK OF EXPLOSION! Never try to

charge non-rechargeable batteries.

• Warning! This electric tool generates an elec-

tromagnetic eld during operation. This eld can

impair active or passive medical implants under

certain conditions. In order to prevent the risk of

serious or deadly injuries, we recommend that per-

sons with medical implants consult with their physi-

cian and the manufacturer of the medical implant

prior to operating the electric tool.

Technical Data

Rated voltage 220-240V~

Heating operation rated output 3000W

Heating time (full tank)

approx.

45min

Shut-off temperature 99°C

Pump delivery rate 0.5 L/min

Rated battery voltage 11.1V

Battery capacity 2000mAH

Battery type Lithium-Ion

Tank contents 20L

Weight 7.6 kg

Before commissioning

• The position of the machine must be stable.

• Before commissioning, all safety devices must be

installed correctly.

• Before connecting the machine, ensure that the

data on the rating plate complies with the mains

data.
