www.scheppach.com www.scheppach.com
7 6
4. Device description (Fig. 1-2)
A. Universal tool stand
B. Support arm
C. Extendible machine base frame extension
D. Adjustable workpiece support
E. Screw
F. Washer
G. Spring washer
H. Nut
I. Star grip screw
5. Unpacking
Keep children away whilst unpacking and assembling
the product. Do not let
children play with the packaging materials.
1. Carefully take the Mitre Saw Stand and all of the
individual parts out of the packaging and remove
all of the packaging materials. If possible, keep
the packaging as additional reference.
2. Check whether the delivery is complete (see Fig.
1-2).
3. Check whether the Mitre Saw Stand or the
individual parts show any signs of damage. If
this is the case, do not use the Mitre Saw Stand.
Contact the manufacturer via the service address
specied on the warranty card.
WARNING!
The device and the packaging are not children‘s
toys! Do not let children play with plastic bags,
lms or small parts! There is a danger of choking
or suocating!
6. Technical data
Dimensions: 935 - 1975 x 645 x 820 - 935 mm
Table height: 775 mm
Height of
the side
expansions:
820 - 935 mm
Min. / max.
spacing of the
supports:
935 - 1975 mm
equivalent purposes.
3. Safety instructions
• Use the Mitre Saw Stand only in conjunction with
suitable electric power tools!
• Check the Mitre Saw Stand for damage each
time before use. Electric power tools shall not be
mounted or operated on damaged support arms
/ crossbars.
• Electric power tools must be bolted to the support
arms / crossbars and be secured on the Mitre
Saw Stand!
• Always ensure the Mitre Saw Stand is secure
when setting it up.
• Always ensure that you assume a natural and
safe standing position when working.
• Do not overload the Mitre Saw Stand! Do not use
the Mitre Saw Stand for purposes for which it is
not intended.
• To prevent the Mitre Saw Stand from tipping over,
make sure that the load does not extend laterally
beyond the Mitre Saw Stand.
• Modications or unauthorised changes to the
Mitre Saw Stand as well as the use of unapproved
parts is forbidden.
• All parts of the Mitre Saw Stand, in particular
the safety devices, must be correctly mounted in
order to guarantee trouble-free operation.
• Keep the Mitre Saw Stand out of reach of children.
Store the device in a location that is inaccessible
to unauthorised persons and children.
CAUTION!
When using electric power tools, in conjunction with
the Mitre Saw Stand, the respective machine-specic
safety measures must be implemented as protection
against electric shock, and the risk of injury or re.
Read all of the instructions for the electric power tool
that you intend to mount and operate before using the
tool.
Safety instructions for the electric device mounted
must likewise be observed.
Store these safety instructions safely.
Observe all safety instructions. If you disregard the
safety instructions, you endanger yourself and others.
2. Fasten the tabletop machine with 4 hexagonal
screws (E), 4 washers (F), 4 spring washers (G)
and 4 hexagonal nuts (H) on each of the support
arms.
3. Tighten the screws (E) after assembly.
4. Fasten the support arms (B) with the mounted
tabletop machine on the universal tool stand, as
described in point 9.3.
If the hole pattern of your machine is not parallel to the
support arms (B), you can use crossbars as adapters.
You can order the crossbars as accessories (see
chapter 11).
Using the workpiece support as a workpiece stop
(g. 9)
The workpiece supports (D) have integrated workpiece
stops (D.2), on both sides which can be used to saw
multiple pieces of wood to the same length.
1. Loosen the star grip screw (I) on the desired
side of the universal tool stand and adjust the
height of the workpiece support (D) such that the
support surface (D.1) is at the same height as the
workpiece support of the saw.
2. Loosen the star grip screw (I) to slide the workpiece
support horizontally.
3. Set the desired distance between the saw blade
and the stop surface (D.2).
4. Lock your setting by tightening the star grip screws
(I) again.
8. Cleaning
• Keep the Mitre Saw Stand as free of dust and dirt
as possible. Rub the Mitre Saw Stand clean with a
clean cloth or blow it o with compressed air at low
pressure.
• We recommend that you clean the Mitre Saw Stand
immediately after every use.
• Clean the device at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents - they could attack the plastic
parts of the Mitre Saw Stand.
Max.
permissible
payload:
150 kg
Weight approx.: 8.6 kg
7. Assembly instructions
The universal tool stand is largely assembled and you
need only t the support arms, the extendible machine
base frame extensions and the workpiece supports as
follows:
Erecting the universal tool stand (g. 3 - 4)
1. Place the universal tool stand (A) on the oor or on
a workbench such that the frame legs (A.1) point
upwards.
2. Press the spring pins (K) and fold out the frame
leg.
3. Once the spring pin (K) latches into the intended
position (J), the frame leg is locked.
4. Repeat this process for the other frame legs.
5. Set the universal tool stand down on its feet.
Fitting the extendible machine base frame
extensions (g. 5)
1. Connect the two extendible base frame extensions
(C) into the frame bed and x them using the star
grip screws (I).
Fitting the support arms (g. 6)
1. Fit the support arms (B) to the frame bed by pulling
the locking lever (B.2) upwards and keep it held to
unlock it. First hook in the support arm (B) on the
rear side (B.1) of the frame bed.
2. Lower the front down onto the frame bed and
release the locking lever (B.2). This xes the
support arm (B) to the frame bed.
3. Disassembly is carried out in reverse order.
Fitting the workpiece supports (g. 7)
1. Insert the workpiece support (D) into the
receptacle (L) of the frame bed and x it via the
star grip screws (I).
2. The height of the workpiece supports can be
adjusted with the star grip screws (I).
Fastening your tabletop machine (g. 8)
Dierent tabletop machines can be fastened to your
universal tool stand by adjusting the support arms (B)
to the spacing of the mounting holes on your machine.
1. Place your tabletop machine (e.g. mitre saw) on
the support arms (B).
