www.scheppach.com
20
|
GB
Installing the paper lter bag (14) (g. 7)
It is recommended to use an additional paper lter bag
(14) when vacuuming ne, dry dirt. Slide the paper lter
bag (14) over the suction opening in the container (7).
The paper lter bag (14) is only suitable for dry vacuu-
ming. The paper lter bag (14) makes it easier to dis-
pose of the dust collected.
Installing the suction hose (g. 8, 9)
Connect the suction hose (12) to the corresponding
port, depending on the desired use, on the wet and dry
vacuum.
Vacuuming:
Connect the suction hose (12) to the suction hose port
(7). To do so, slide the end of the suction hose (12)
into the suction hose port (7). Make sure the plug-in
tting on the end of the suction hose (12) latches into
the recess on the suction hose connection (7). In the
end position, turn the suction hose (12) in a clockwise
direction.
Blowing:
Connect the suction hose (12) to the suction hose port
(10). Make sure the plug-in tting on the end of the suc-
tion hose (12) latches into the recess on the connection
with blast function (10).
In the end position, turn the suction hose (12) in a
clockwise direction.
Installing the plastic extension tubes, suction
hose and oor nozzle (g. 10)
Assemble the plastic extension tubes (17) by pushing
them together. Connect the assembled plastic exten-
sion tubes with the bent end of the suction hose (12).
Fit the oor nozzle (15) or joint nozzle (16) to the other
end of the assembled plastic extension tubes.
8. Operation
Warning! Switch the device o if liquid or foam
emerges with the exhaust air during wet vacuu-
ming.
Switching on/o (g. 1)
Press the on/o switch (8):
• Switch setting 0: O
• Switch setting I: On
Dry vacuuming
Use the paper lter bag (14) for dry vacuuming.
m WARNING!
This electric tool generates an electromagnetic eld
during operation. This eld can impair active or passi-
ve medical implants under certain conditions. In order
to prevent the risk of serious or deadly injuries, we re-
commend that persons with medical implants consult
with their physician and the manufacturer of the medi-
cal implant prior to operating the electric tool.
6. Technical Data
Mains voltage 220-240 V~ 50/60 Hz
Power 1200 W
Water tank capacity 16 l
Suction performance 20 kPA
Protection category IP24
Protection class II
7. Installation
m IMPORTANT!
Prior to use, ensure that the device has been correct-
ly and fully assembled.
Unpacking (g. 1, 2, 3)
1. Release the locking hooks (4) and remove the ma-
chine head (2). The accessories are located inside
the container (6). Only the plastic extension tubes
(3x) are located outside the container (6), in the
packaging. Remove all of the accessories from the
container (6).
Installing the castors (g. 4)
1. Press the four castors (5) into the holes in the castor
mounts.
Installing the machine head (2) (g. 5)
1. Place the machine head (2) on the container (6). Se-
cure the machine head (2) with the locking hooks (4).
When installing the machine head (2), ensure that
the locking hooks (4) latch into place correctly.
Installing the foam lter (13) (g. 6)
Never use the device without lter! Always ensure that
the lters are correctly tted!
Installing the foam lter (13): For wet vacuuming, slide
the foam lter (13) provided over the lter basket with
safety oat valve (11).
