www.scheppach.com
28
|
GB
12a. Loop
12b. Metal tab
13. Fillister head screw
14. Limiting blade
15. Trim plate
16. Idler
17. Oil dipstick
18. Fuel tank
19. Fuel ller cap
20. Plastic star grip nut
20a. Round-head screw
20b. Washer
21. Pull starter
22. Carburettor
23. Drain screw
3. Scope of delivery
Item Quantity Designation
4 1x Meadow mower with upper
push bar
4a 1x Lower push bar
4 1x Upper push bar
20a 4x Round-head screw
20b 4x Washer
20 4x Plastic star grip nut
5 1x Cable clip
13 2x Fillister head screw
11 10x Cutting thread with sheath
1x Operating manual
4. Proper use
The meadow mower is suitable for private use in do-
mestic and hobby gardens. Meadow mowers for pri-
vate domestic and hobby gardens are considered to
be those whose annual use does not generally ex-
ceed 50 hours and which are primarily used for the
maintenance of grass or meadow areas, but not in
public areas, parks, sports facilities or in agriculture
and forestry.
The product may only be used in the intended man-
ner. Any use beyond this is improper. The user/opera-
tor, not the manufacturer, is responsible for damages
or injuries of any type resulting from this.
An element of the intended use is also the obser-
vance of the safety instructions, as well as the as-
sembly instructions and operating information in the
operating manual.
Persons who operate and maintain the product must
be familiar with the manual and must be informed
about potential dangers.
1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoy-
ment and success.
Note:
In accordance with the applicable product liability
laws, the manufacturer of this product assumes no
liability for damage to the product or caused by the
product arising from:
• Improper handling
• Failure to comply with the operating manual
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts
• Improper use
• Failure of the electrical system in the event of the
electrical regulations and VDE provisions 0100,
DIN 57113 / VDE 0113 not being observed
Note:
The operating manual is part of this product. It in-
cludes important instructions for the safe, proper
and economic operation of the product, for avoiding
danger, for minimising repair costs and downtimes
and for increasing the reliability and extending the
service life of the product. In addition to the safety
instructions in this operating manual, you must also
observe the regulations applicable to the operation of
the product in your country.
Familiarise yourself with all operating and safety in-
structions before using the product. Only operate the
product as described and for the specied areas of
application. Keep the operating manual in a good
place and hand over all documents when passing the
product on to third parties.
2. Product description (Fig. 1)
1. Handle
2. Engine brake lever
3. Cable pull
4. Upper push bar
4a. Lower push bar
5. Cable clips
6. Spark plug
7. Primer button
8. Air lter
9. Exhaust pipe
10. Hexagonal bolt
11. Cutting thread
12. Spindle
