www.scheppach.com
30
|
GB
11. Electrical connections
• Before you connect the appliance to the mains sup-
ply make sure that the data on the rating plate are
identical to the mains data.
• If you use any extension cables, make sure that
they are suitable for outdoor use and have large
enough wires:
1–10 m: 1,5 mm
2
10–30 m: 2,5 mm
2
• Plug the mains plug on the power cable into the
mains socket outlet.
• The product meets the requirements of EN 61000-
3-11 and is subject to special connection condi-
tions. This means that use of the product at any
freely selectable connection point is not allowed.
• Given unfavourable conditions in the power supply
the product can cause the voltage to uctuate tem-
porarily.
• The product is exclusively intended for use at con-
nection points that have a continuous current-car-
rying capacity of at least 100 Ampere phase.
• As the user, you are required to ensure, in consulta-
tion with your electric power company if necessary,
that the connection point at which you wish to oper-
ate the product meets the specied requirements.
12. Operation
The equipment consists of an assembly with a pump,
which is encased in a shock absorbing housing. The
equipment comes with a lance and a non-slip gun (for
an optimal working position), whose shape and con-
guration comply with the applicable regulations.
Commissioning:
Once you have completely assembled the high-pres-
sure cleaner and all connections have been made,
proceed as follows:
Turn on the water supply. Unlock the pistol (13) via
the locking switch (C). Pull back the trigger lever (D)
so that the air in the device can discharge. (Fig. 4)
Switch on the device by setting the on/o switch (4)
to “ON”. Next, press the trigger lever (D). (Fig. 1/4)
To switch o, release the trigger lever (D), and the
device switches to stand-by. The high-pressure
cleaner starts again when you press the trigger le-
ver (D). (Fig. 4)
To switch o the high-pressure cleaner completely,
set the on/o switch (4) to “OFF”. (Fig. 1)
Cleaner container (9)
Fill the cleaner container with the corresponding
cleaner. The beam width can be adjusted at the noz-
zle.
10. Assembly
Device assembly (g. 4)
Push the handle (1) onto the fastening points at the
top of the device and secure using the two screws
provided (length 20 mm)
Water supply connection (g. 2)
Screw the connection for the water supply (10) onto
the device. The connection for the water supply (10)
features a connection for standard hose coupling
systems. Attach the hose coupling of the supply hose
(min. Ø 1/2“/ approx. 13 mm) onto the connection for
the water supply (10) .
Always use an enhanced water hose with an in-
dustry-standard coupling for the water supply. The
length should be at least 6.0 m (not included in the
scope of delivery).
A backow prevention device must be installed be-
tween the drinking water and the high-pressure
cleaner! Ask your plumbing expert about this.
Suction from open tanks/containers and natural
bodies of water
Use a special self-suction accessory (not included
with delivery / available from dealer).
With this accessory, the high-pressure cleaner can
take in water 0.5 m above the water level. This can
last about 25 to 50 seconds.
Immerse the accessory’s hose completely under wa-
ter to drive the air out of the hose.
Connect the accessory’s hose to the high-pressure
cleaner, and make sure that the suction strainer re-
mains under water.
Let the high-pressure cleaner run with the spray gun
removed until the water ows evenly out of the high-
pressure hose.
If no water comes out after 25 to 50 seconds, switch
o and check all connections.
Once the water is owing, turn o the high-pressure
cleaner and connect the spray gun and spray lance
to start work.
High-pressure hose connection (g. 3/4)
Connect the high-pressure hose (2) to the connec-
tion for the high-pressure hose (6). Remove the pro-
tective cover rst.
Insert the other end of the high-pressure hose (2)
into the pistol connection (13).
To remove the high-pressure hose (3), press the but-
ton Taste (A) and pull it out.
Connecting the attachments (g. 5)
To mount attachments 14, 17, 18, press them into
the pistol (13) and turn them until the lock.
To mount attachments 12, 15, 16, 19, insert these
into the attachment (14) and turn them until they lock.
